PROCAMTM

Surface coating solution We have various functional coating products using nano-particle sol.
  • High Performance
    Coating Solution
  • High Functional
    Monomer
  • Syper Hydrophobic
    Solution

Vacuum Evaporation Coating Materials

Vacuum Evaporation Coating System
High-purity films can be doposited from high-purity source material. Source of mateiral to be vaporized may be a solid in any form any purity. Decomposition rate monitoring and control are relatively easy.

Vaccum Coating Materials

Al2O3 (Aluminum Oxide)
  • Transmission Range
    200~5,000nm
  • Melting Point
    2,040℃
  • Evaporation Temperature
    2,000 ~ 2,200℃
  • Density
    3.9g/cm2
  • Application
    Multilayers Protective Films
SiO (Silicon Monoxide)
  • Transmission Range
    800~8,000nm
  • Melting Point
    1,705℃
  • Evaporation Temperature
    1,100 ~ 1,800℃
  • Density
    >2.5g/cm2
  • Application
    Multilayers Protective Films
SiO2 (Silicon Dioxide)
  • Transmission Range
    200~2,500nm
  • Melting Point
    1,700 ~ 1,800℃
  • Evaporation Temperature
    1,800 ~ 2,200℃
  • Density
    >2.2g/cm2
  • Application
    Multilayers Protective Films
MgF2 (Magenesium Flouride)
  • Transmission Range
    200~7,000nm
  • Melting Point
    1,261℃
  • Evaporation Temperature
    1,300 ~ 1,600℃
  • Density
    >2.8g/cm2
  • Application
    Antireflection Coatings, Protective Films,
    Multilayers on Glass Plastic and Jewelry
ZrO2 (Zirconium Dioxide)
  • Transmission Range
    350~7,000nm
  • Melting Point
    2,700℃
  • Evaporation Temperature
    2,500℃
  • Density
    >4.7g/cm2
  • Application
    Anti-reflection Coatings, Multilayers
TiO2 (Titanium Dioxide)
  • Transmission Range
    350~14,000nm
  • Melting Point
    1,650℃
  • Evaporation Temperature
    1,800 ~ 2,000℃
  • Density
    4.2g/cm2(Rutile), 3.8g/cm2(Anatase)
  • Application
    High Refractive Layers for Multilayers
ITO (Indium Tin Oxide)
  • Transmission Range
    400~1,000nm
  • Melting Point
    1,800℃
  • Evaporation Temperature
    1,800 ~ 2,000℃
  • Density
    >4.7g/cm2
  • Application
    Conductive Transparent Layers
Ti3O5 (Trititanium Pentoxide)
  • Transmission Range
    400~12,000nm
  • Melting Point
    1,750℃
  • Evaporation Temperature
    1,800 ~ 2,000℃
  • Density
    >4.57g/cm2
  • Application
    Anti-reflection Coatings, Interference Filters,
    Protective Films, Beam Splitters, Jewelry
CrSiO (Chromium Silicon Monoxide, MX-Series)
  • Transmission Range
    360~10,000nm
  • Melting Point
    1,350℃
  • Evaporation Temperature
    1,800 ~ 2,000℃
  • Density
    >5.3g/cm2
  • Application
    Adhesion promotor of multilayers

Regarding the evaporation coating materials, please contact our expert for more detailed information
